Code: F6-9SF-208230003
MPN: 208230003
Retsch ZM200 For 120 V 50/60HZ 208230003 is one of the many quality laboratory and scientific products we have to offer at very competitive pricing. Retsch ZM200 For 120 V 50/60HZ 208230003 / 16003-482 is part of a wide selection of Retsch Laboratory crushers or pulverizers. Combining excellent quality with an affordable price, the Retsch ZM200 For 120 V 50/60HZ 208230003 / 16003-482 can meet your scientific research needs while still offering a good value for a budget conscious end user. If you have any questions about any of our Laboratory crushers or pulverizers please do not hesitate to contact our customer service for further guidance.![]()
For fine grinding of soft to medium-hard and fibrous materials. With rotor/screen system and extensive range of accessories, this mill is ideally suited for quality control, research and development, and small-scale production. Mill includes a 900mL cassette for simple removal of ground material and to eliminate cross-contamination. The cassette consists of a collecting pan and cover. After grinding, the cassette can be removed completely with ring sieve and ground material. Feed material is introduced manually or via an optional load-controlled vibratory feeder (16003-534). The mill also has a microprocessor-controlled safety and diagnosis system. Features safety plastic housing with automatic cover closure and a motor compartment fully protected against dust and material penetration. For grinding larger volumes, the 5L cyclone with passage receptacle (16003-574) can be used with the mill.
Push-fit rotors and sieves are selected according to the material to be ground, the degree of fineness required, and the subsequent analysis. Coated rotors and sieves feature a wear-resistant coating.
| Description: | ZM 200 Mill, 120V, 50/60Hz |
| Retsch No.: | 208230003 |
| Unit: | Each |
| Properties: | |
| Feed Size: | Up to 10 mm |
| Grind Size*: | <40 µm |
| Maximum Sample Volume: | 900 mL |
| Speed Range: | 6,000-18,000 rpm |
| Sound Emission Level: | Up to 77.5 dB (A) |
| Dimensions: | 41W x 36.5H x 51.5D cm |
| Weight: | 38 kg (83.8 lbs.) |
| *Depending on sample. | |
