Product No Longer Available
Unfortunately Carl Zeiss Microscopy 15x/13 Br. Focusing Eye Piece For Stemi DV4 Stereomicroscope is not listed by LabPlanet.You can also explore other items in the Microscope Accessories yourself to try and find the perfect replacement for you!
Product Info for Carl Zeiss Microscopy 15x/13 Br. Focusing Eye Piece For Stemi DV4 Stereomicroscope
Carl Zeiss Microscopy Focusing Eyepiece 15x/13 is a reliable microscope accessory for the Stemi DV4 Stereomicroscope. The Focusing Eye Piece 15x/13 by Carl Zeiss Microscopy will enhance the total magnification range of an object depending on what type of front lens system is attached to the eyepiece.
Note: A set of 2 Focusing Eyepieces must be ordered in order for Stemi DV4 Stereomicroscope to be operated.
Carl Zeiss Microscopy has a range of well chosen Zeiss Microscope Accessories to make the Stemi DV4 Stereomicroscope an even more attractive option for a whole range of applications, all available for sale at our online store. For a larger selection of other microscopes on sale, check out the Microscope Accessories and microscope accessories section for further enhancements and compatible solutions.
Specifications of Carl Zeiss Microscopy 15x/13 Br. Foc for Stemi DV4 Stereomicroscope:
Total Magnification Ranges when used with Front Lens System Attachments
Front lens system | Eyepiece 15x/13 Br. foc. | ||
|---|---|---|---|
Factor | Free Working Distance (mm) | Magnification | Object field (mm) |
0,3x | 287 | 3,6x ... 14,4x | 55,4 ... 13,9 |
0,4x | 211 | 7,6x ... 30,2x | 41,6 ... 10,4 |
0,3x ... 0,5x | 233 ... 90 | 3,6x ... 24,0x | 55,4 ... 8,3 |
0,63x | 130 | 7,5x ... 30,3x | 26,4 ... 6,6 |
without | 92 | 12,0x ... 48,0x | 16,6 ... 4,2 |
1,25x | 60 | 15,0x ... 60,0x | 13,3 ... 3,3 |
1,6x | 48 | 19,2x ... 76,8x | 10,4 ... 2,6 |
2x | 31 | 24,0x ... 96,0x | 8,3 ... 2,1 |
Features of Zeiss Microscopy 435062-9000-000 15x/13 Br. Focusing Eyepiece for Stemi DV4 Stereo Microscope
- Compatible with the Stemi DV4 Stereomicroscope
Package Content
- Carl Zeiss Microscopy Focusing Eyepiece 15x/13 Br. Foc. For Stemi DV4 Stereomicroscope 435062-9000-000
