Labconco FreeZone Plus Freeze Dry Systems, 6 L and 12 L Cascade, Labconco 7934020 6 L Models Cascade System
Tap Tap to Zoom
Product No Longer Available
Unfortunately Labconco FreeZone Plus Freeze Dry Systems, 6 L and 12 L Cascade, Labconco 7934020 6 L Models Cascade System is not listed by LabPlanet.You can also explore other items in the Freeze dryers or lyopholizers, Centrifugation, Centrifuges yourself to try and find the perfect replacement for you!
Product Info for Labconco FreeZone Plus Freeze Dry Systems, 6 L and 12 L Cascade, Labconco 7934020 6 L Models Cascade System
Labconco FreeZone Plus Freeze Dry Systems, 6 L and 12 L Cascade, Labconco 6 L Models Cascade System is a reliable and dependable addition to the Labconco Centrifuges family of products. Combining top-notch and uncompromising quality with an affordable price, the Labconco FreeZone Plus Freeze Dry Systems, 6 L and 12 L Cascade, Labconco 6 L Models Cascade System 7934020/ 82019-132 can fulfill your laboratory needs while still offering a great value for the money.
Product Category Description:
Dual CFC- and HCFC-free refrigeration systems cool collector to –84°C (–119°F). Models have brushed stainless steel and glacier white, epoxy-coated steel exterior with blue accents. Equipped with automatic one-button start-up to initiate collector and vacuum, dual LCD screens for vacuum and collector temperatures with LED “waves” to indicate proper conditions, a 22.9cm (9") condenser drain hose, and a 7.6cm (3") diameter stainless steel port for connection of drying accessories.
All models feature a red alarm light to indicate any abnormal system events such as power failure or improper line voltage supply, a moisture sensor that detects moisture in the collector chamber area, a vacuum break valve that bleeds air into the system when power to dryer or vacuum pump is shut off, and a rear-mounted RS-232 port. Models include hot gas defrost and switch with automatic hot gas shut-off when collector coil reaches 65°C (149°F).
The optional purge valve, located between the pump and the condenser, helps extend pump life, prevent back streaming of vacuum pump and minimize the chance of contamination of samples if power is interrupted. Models with the built-in vacuum drying chamber include a heater with microprocessor control from –40 to 60°C (–40 to 140°F). Vacuum drying chamber measures 13.6Wx33Dx6.4Hcm (513/32x13x21/2").
UL listed and CSA certified.
Ordering Information: Models include a three-wire cord with either a 20A plug (115V models) or a 15A plug (208/230V models) and a 1.9cm (3/4") I.D. vacuum hose with two clamps for connection to a vacuum pump. All models require a minimum 144L/min. vacuum pump as well as a drying chamber or manifold for operation. All models are also available with an optional fluoropolymer resin-coated collector chamber ideal for processes involving corrosive compounds. For Fast-Freeze* flasks, see 26675-228 series. For vacuum pumps, drying chamber, manifolds, models with coated collector, and models with international electrical configurations, contact our sales representative.
Specifications for Labconco FreeZone Plus Freeze Dry Systems, 6 L and 12 L Cascade, Labconco 7934020 6 L Models Cascade System:
| Description: | Cascade System | |
| Electrical*: | 115V, 60Hz, 11A | |
| Shipping Weight, kg (lbs.): | 150 (330) | |
| Labconco No.: | 7934020 | |
| Unit: | Each (6 L) | |
| Condenser, 12 L Model: | 1/2 hp | |
| Water Removal Capacity, 6 L Model: | 2 L/24 hrs. | |
| Water Removal Capacity, 12 L Model: | 6 L/24 hrs. | |
| Water Removal Capacity, Dimensions: | 80.8W x 71.1D x 92.1H cm (3113/16 x 28 x 361/4") | |
